Hot selling product solar controller 24V 48V household system Bluetooth control LED screen 60A small household appliances

Price	R 5,916.74	R 5,722.11	R 5,332.87
Qty	100 - 149	150 - 199	≥ 200

Min qty:

100

Exclude International Delivery :

Estimate Shipping Cost>

Review :

sales volume in 30 days

retention rate

model :

MF4860N15

0 in stock R 5,916.74

R 0.00

一、产品特点

采用PowerCatcher最大功率追踪技术。
同时支持满功率充电和放电。
支持并机充电。
支持锂电池，控制器输出主动稳压,因此具备良好的锂电激活功能。
支持温度补偿功能。
预设多种电池类型。
自带液晶屏实时数据交互。
具有完善超压、过流、过载、过温、短路、反接等保护机制。
采用自然散热和风扇散热。
支持Modbus协议。

二、规格参数

参数名称	参数值
系统电压	12V/24V/36V/48V
空载损耗	0.5W
蓄电池电压	9V~64V
最大PV开路电压	140V
最大功率点电压范围	(电池电压+2)~120V
额定充电电流	60A
额定负载电流	40A
太阳能板功率	800W/12V; 1600W/24V; 2400W/36V; 3200W/48V
充电转换效率	≤98%
MPPT追踪效率	＞99%
光控开电压	5V*n
光控关电压	6V*n
光控延时	白天转晚上延时时间5分钟(默认)；晚上转白天1分钟
通信方式	隔离RS485 ：波特率9600，数据位8，停止位1，无校验位；默认地址1
冷却方式	自然散热+风扇散热
并机充电	通过连接RS485通讯线，可多台控制器并机充电
电池外部温度采样	用于电池温度保护和铅酸电池温度补偿
保护功能	电池过充保护、电池过放保护、电池反接保护、PV防反接保护、夜间防反充保护、内部过温保护、充电过流保护、负载过流保护、负载短路保护、风扇故障保护等
工作温度	-10℃～+65℃
海拔高度	≤ 3000米
防护等级	IP32
重量	3.6kg
产品尺寸	27516790mm
